Product Summary
The HEF4052BT is a dual 4-channel analogue multiplexer/demultiplexer with common channel select logic. Each multiplexer/demultiplexer has four independent inputs/outputs (Y0 to Y3) and a common input/output (Z). The common channel select logic includes two address inputs (A0 and A1) and an active LOW enable input (E).
Parametrics
Absolute maximum ratings: (1)ON resistance: 350 Ω typ and 2500 Ω max at Vis = 0 to VDD-VEE; (2)‘△’ ON resistance between any two channels: 25 Ω typ at Vis = 0 to VDD-VEE; (3)OFF-state leakage current, all channels: 1000 nA max; (4)OFF-state leakage current, any channel: 200 nA at E at VSS.
Features
Features: (1)Limiting values in accordance with the Absolute Maximum System (IEC 134); (2)Supply voltage (with reference to VDD): -18 to + 0,5 V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HEF4052BT,652 |
NXP Semiconductors |
Multiplexer Switch ICs DL 4CH ANLG MUX/DMUX |
Data Sheet |
|
|
||||||||||||
|
HEF4052BT,653 |
NXP Semiconductors |
Multiplexer Switch ICs DUAL 4-CHANNEL |
Data Sheet |
|
|
||||||||||||
|
HEF4052BTD |
NXP Semiconductors |
Multiplexer Switch ICs DL 4CH ANLG MUX/DMUX |
Data Sheet |
