Product Summary

The IRU3065CLTR is a positive to negative DC to DC controller. It is designed to provide solutions for the applications requiring low power on board switching regulators. The device is specifically designed for positive to negative conversion and uses few components for a simple solution. The IRU3065CLTR operates at high switching frequency (up to 1.5MHz), resulting in smaller magnetics. Applications include: Hard Disk Drives, Blue Laser for DVD R-W, MR Head Bias, LCD Bias, GaAs FET Bias, Positive-to-Negative Conversion.

Parametrics

IRU3065CLTR absolute maximum ratings: (1)Vcc: 7V; (2)VDD: 12V; (3)Operating Junction Temperature Range: 0℃ To 125℃; (4)Operating Ambient Temperature Range: 0℃ To 70℃; (5)Storage Temperature Range: -65℃ To +150℃; (6)ESD Capability (Human Body Model): 2000V.

Features

IRU3065CLTR features: (1)Generate Negative Output from +5V Input; (2)1A Maximum Output Current; (3)1.5MHz maximum Switching Frequency; (4)Few External Components; (5)Available in 6-Pin SOT-23.

Diagrams

IRU3065CLTR block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRU3065CLTR
IRU3065CLTR


IC REG CTRLR INV PWM SOT23-6

Data Sheet

0-1: $1.16
1-25: $0.66
25-100: $0.58
100-1000: $0.48
