Product Summary

The EM78P458APJ is an 8-bit microprocessor designed and developed with low-power and high-speed CMOS technology. It is equipped with a 4K*13-bit Electrical One Time Programmable Read Only Memory (OTP-ROM). With its OTP-ROM feature, the EM78P458APJ is able to offer a convenient way of developing and verifying user’s programs. Moreover, user can take advantage of EMC Writer to easily program his development code.

Parametrics

EM78P458APJ absolute maximum ratings: (1)Temperature under bias: 0 to 70℃; (2)Storage temperature: -65 to 150℃; (3)Input voltage: -0.3V to +6.0V; (4)Output voltage: -0.3V to +6.0V.

Features

EM78P458APJ features: (1)Operating voltage range: 2.3V~5.5V ; (2)Operating temperature range: 0~70℃; (3)Low power consumption; (4)4K × 13 bits on chip ROM; (5)84 × 8 bits on chip registers (SRAM); (6)2 bi-directional I/O ports; (7)8 level stacks for subroutine nesting; (8)8-bit real time clock/counter (TCC) with selective signal sources, trigger edges, and overflow interrupt; (9)8-bit multichannel Analog-to-Digital Converter with 8-bit resolution; (10)Dual Pulse Width Modulation (PWM ) with 10-bit resolution; (11)One pair of comparators; (12)Power-down (SLEEP) mode; (13)Six available interruptions; (14)Programmable free running watchdog timer; (15)8 Programmable pull-down I/O pins; (16)7 programmable pull-high I/O pins; (17)8 programmable open-drain I/O pins; (18)Two clocks per instruction cycle.

Diagrams

EM78P458APJ block diagram
