Product Summary
The S6B-PH-SM4-TB is a thin, low-profile 2.0mm pitch connector 8.0mm in height after mounting and 4.5mm in width. It is designed to meet the demand for high-density connection of internal wires to printed circuit boards. The S6B-PH-SM4-TB is compact, highly reliable and low in cost.
Parametrics
S6B-PH-SM4-TB absolute maximum ratings: (1)Current rating: 2A AC, DC (AWG #24); (2)Voltage rating: 100V AC, DC; (3)Temperature range: -25 to +85℃; (4)Contact resistance: Initial value/10mΩ max. After environmental testing/20mΩ max; (5)Insulation resistance: 1,000MΩ min; (6)Withstanding voltage: 800V AC/minute; (7)Applicable wire: AWG #32 to #24; (8)Applicable PC board thickness: 0.8 to 1.6mm.
Features
S6B-PH-SM4-TB features: (1)Reliable contact; (2)Fully shrouded header; (3)Printed circuit board retention mechanism; (4)Surface mount model (SMT).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 S6B-PH-SM4-TB(LF)(SN) |
JST Sales America Inc (VA) |
CONN HEADER PH SIDE 6POS 2MM SMD |
Data Sheet |
|
|
||||||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||||||
 |
S6B-EH(LF)(SN) |
JST Sales America Inc |
CONN HEADER EH SIDE 6POS 2.5MM |
Data Sheet |
|
|
||||||||||||||||
 |
S6B-PH-K-S |
JST Sales America Inc |
CONN HEADER PH SIDE 6POS 2MM |
Data Sheet |
Negotiable |
|
||||||||||||||||
|
S6B-PH-K-S(LF)(SN) |
JST Sales America Inc |
CONN HEADER PH SIDE 6POS 2MM |
Data Sheet |
|
|
||||||||||||||||
|
S6B-PH-SM4-TB(LF)(SN) |
JST Sales America Inc (VA) |
CONN HEADER PH SIDE 6POS 2MM SMD |
Data Sheet |
|
|
||||||||||||||||
(SN).JPG "S6B-XH-A(LF)(SN)") |
S6B-XH-A(LF)(SN) |
JST Sales America Inc |
CONN HEADER XH SIDE 6POS 2.5MM |
Data Sheet |
|
|
||||||||||||||||
(SN).JPG "S6B-XH-SM4-TB(LF)(SN)") |
S6B-XH-SM4-TB(LF)(SN) |
JST Sales America Inc (VA) |
CONN HEADER XH SMD 6POS 2.5MM |
Data Sheet |
|
|
||||||||||||||||
