Product Summary
The TCD1304DG is a high sensitive and low dark current 3648-elements linear image sensor. The sensor can be used for POS scanner. The device consists of sensitivity CCD chip. The TCD1304DG has electronic shutter function (ICG).
Parametrics
Absolute maximum ratings: (1)Master Clock Pulse Voltage: -0.3~7 V; (2)SH Pulse Voltage: -0.3~7 V; (3)ICG Pulse Voltage : -0.3~7 V; (4)Digital Power Supply: -0.3~7 V; (5)Analog Power Supply: -0.3~7 V; (6)Operating Temperature: -25~60 ℃; (7)Storage Temperature: -40~100 ℃.
Features
Features: (1)Pixel Number : 3648; (2)Pixel Size : 8μm×200μm; (3)Photo Sensing Region: High Sensitive & Low Dark Current pn Photodiode; (4)Internal Circuit : CCD Drive Circuit; (5)Power Supply : Only 3.0V Drive (MIN.); (6)Function : Electronic Shutter Sample and Hold Circuit; (7)Package : 22 Pin CERDIP PACKAGE.
