Product Summary

The 20SVP150M is a Standard SMD type capacitor.

Parametrics

20SVP150M absolute maximum ratings: (1)Capacitance: 150μF; (2)Capacitance Tolerance: ± 20%; (3)Voltage Rating: 20V; (4)ESR: 0.02ohm; (5)Life Time @ Temperature: 2000 hours @ 105℃; (6)Height: 10.3mm; (7)Diameter: 10mm; (8)Operating Temperature Range: -55 to +105℃; (9)RoHS Compliant: Yes.

Features

20SVP150M features: (1)Standard SMD type product; (2)Use for surface mounted type switching power supplies; (3)This product can support lead free-reflow.

Diagrams

20SVP150M dimensions
