IR2131

high speed power MOSFET, IGBT driver, high voltage, -0.3 to 625V, 2.5V logic compatible

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.50

PartNumber:: IR2131

Brand:: International Rectifier - IR | Pack: SOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tesi's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-07

From Other Seller

Part Number:IR2131
US $0.30 - 0.50
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IR2131 is a high voltage, high speed power MOSFET and IGBT driver with three independent high and low side referenced output channels. Proprietary HVIC technology enables ruggedized monolithic construction. Logic inputs are compatible with CMOS or LSTTL outputs, down to 2.5V logic. A current trip function which terminates all six outputs can be derived from an external current sense resistor. A shutdown input is provided for a customized shutdown function. The IR2131 can be used to drive N-channel power MOSFETs or IGBTs in the high side configuration which operate up to 600 volts.

Parametrics

IR2131 absolute maximum ratings: (1)VB1,2,3 High Side Floating Supply Voltage: min=-0.3 V, max=625 V; (2)VS1,2,3 High Side Floating Offset Voltage: min=VB1,2,3 -25 V, max=VB1,2,3 + 0.3 V; (3)VHO1,2,3 High Side Floating Output Voltage: min=VS1,2,3 - 0.3 V, max=VB1,2,3 + 0.3 V; (4)VCC Low Side and Logic Fixed Supply Voltage: min=-0.3 V, max=25 V; (5)VSS Logic Ground: min=VCC - 25 V, max=VCC + 0.3 V; (6)VLO1,2,3 Low Side Output Voltage: min=-0.3 V, max=VCC + 0.3 V; (7)VIN Logic Input Voltage (HIN1,2,3 ,LIN1,2,3 ,FLT -CLR ,SD&ITRIP): min=VSS - 0.3 V, max=(VSS + 15) V or (VCC + 0.3) V whichever is lower.

Features

IR2131 features: (1)Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune; (2)Gate drive supply range from 10 to 20V; (3)Undervoltage lockout for all channels; (4)Over-current shutdown turns off all six drivers; (5)Independent 3 high side & 3 low side drivers; (6)Matched propagation delay for all channels; (7)2.5V logic compatible; (8)Outputs out of phase with inputs.
