Product Summary
The S3C8629X48-AQB9 is an 8-bit single-chip CMOS microcontroller. It offers a fast and efficient CPU with a wide range of integrated peripherals, in various mask-programmable ROM sizes. The device is based on the powerful SAM8 CPU architecture. The internal register file is logically expanded to increase the on-chip register space. The S3C8629X48-AQB9 contains 16/32 K bytes of on-chip program ROM. It is ideal for use in multi-sync monitors or in general-purpose applications that require sophisticated timer/counter, PWM, sync signal processing, A/D converter, and multi-master IIC-bus support with DDC.
Parametrics
S3C8629X48-AQB9 absolute maximum ratings: (1)Supply voltage VDD: -0.3 to + 6.5 V; (2)Input voltage VI1: -0.3 to + 7.0 V; VI2: -0.3 to VDD + 0.3 V; (3)Output voltage VO: -0.3 to VDD + 0.3 V; (4)Output current High IOH: -10 mA; (5)All I/O pins active – 60; (6)Output current Low IOL: 30 mA; (7)Operating temperature TA: -40 to + 85 ℃; (8)Storage temperature TSTG: -65 to + 150 ℃.
Features
S3C8629X48-AQB9 features: (1)Normal Multi-Master IIC-Bus 1-Ch: Serial Peripheral Interface; (2)A/D Converter: 4-channel; 8-bit resolution; (3)Oscillator Frequency: 8 MHz to 12 MHz crystal operation; Internal Max. 12 MHz CPU clock; (4)Operating Temperature Range: -40 ℃ to + 85 ℃; (5)Operating Voltage Range: 4.0 V to 5.5 V; (6)Package Types: 42-pin SDIP, 44-pin QFP.
