88E1111-B1-BABI000

88E1111-XX-BAB-I000, Integrated 10/100/1000 Ultra Gigabit Ethernet, BGA, Marvell Virtual Cable Tester

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.00~12.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $10.00~12.00

PartNumber:: 88E1111-B1-BABI000

Brand:: Marvell Technology Group Ltd - MARVELL | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tesi's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-24

From Other Seller

Part Number:88E1111-B1-BABI000
US $10.00 - 12.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 88E1111-B1-BABI000 device incorporates the Marvell Virtual Cable Tester feature, which uses Time Domain Reflectometry (TDR) technology for the remote identification of potential cable malfunctions, thus reducing equipment returns and service calls. Using VCT, the Alaska 88E1111-B1-BABI000 device detects and reports potential cabling issues such as pair swaps, pair polarity and excessive pair skew. The 88E1111-B1-BABI000 will also detect cable opens, shorts or any impedance mismatch in the cable and report accurately within one meter the distance to the fault.

Parametrics

88E1111-B1-BABI000 characteristics: (1)Supports GMII, TBI, reduced pin count GMII (RGMII), reduced pin count TBI (RTBI), and serial GMII (SGMII) interfaces; (2)Fully integrated digital adaptive equalizers, echo cancellers, and crosstalk cancellers; (3)117-Pin TFBGA and 96-Pin BCC packages available in Commercial or Industrial grade.

Features

88E1111-B1-BABI000 features: (1)10/100/1000BASE-T IEEE 802.3 compliant; (2)Integrated 1.25 GHz SERDES for 1000BASE-X fiber applications; (3)Four RGMII timing modes; (4)Energy Detect and Energy Detect+ low power modes; (5)Three loopback modes for diagnostics; (6)Advanced digital baseline wander correction; (7)Automatic MDI/MDIX crossover at all speeds of operation; (8)Automatic polarity correction; (9)IEEE 802.3u compliant Auto-Negotiation; (10)Software programmable LED modes including LED testing; (11)Automatic detection of fiber or copper operation; (12)Supports IEEE 1149.1 JTAG; (13)Two-Wire Serial Interface (TWSI) and MDC/MDIO; (14)CRC checker, packet counter; (15)Packet generation; (16)Virtual Cable Tester (VCT); (17)Auto-Calibration for MAC Interface outputs; (18)I/Os are 3.3V tolerant; (19)Low power dissipation Pave = 0.75W; (20)117-Pin TFBGA, 96-Pin BCC, and 128 PQFP package options; (21)RoHS 6/6 compliant packages available.
