Product Summary

The MC13143D is a high compression linear mixer with single–ended RF input, differential IF output and differential LO inputs which consumes as little as 1.8 mW. A new circuit topology is used to achieve a high third order intermodulation intercept point, high linearity and high 1.0 dB output compression point while maintaining a linear 50 W input impedance. The MC13143D is designed for Up or Down conversion anywhere from dc to 2.4 GHz.

Parametrics

MC13143D absolute maximum ratings: (1)Power Supply Voltage VCC(max): 7.0 Vdc; (2)Junction Temperature TJmax: 150 ℃; (3)Storage Temperature Range Tstg: –65 to 150 ℃.

Features

MC13143D features: (1)50 Ω Mixer Input; (2)Single-ended Mixer Input; (3)Double Balanced Mixer Operation; (4)Differential Open Collector Mixer Output.

Diagrams

MC13143D diagram
