Product Summary

The AC101LKQTG is a 10/100 base-tx single-phy transceiver.

Features

AC101LKQTG features: (1)Single port: 10BASE-T/100BASE-TX/100BASE-FX, Full Duplex or Half Duplex; (2)Power Supply: 2.5V or 3.3V; (3)Integrated voltage regulator to allow operation from single supply source; (4)Single port-MII or RMII; (5)HPAuto-MDIX; (6)Very small package-48-pin TQFP 49 sq. mm footprint; (7)Very low power-Typical < 200mW (100BASE-TX); (8)Fully compliant with IEEE 802.3 / 802.3u; (9)Baseline wander correction; (10)Multi-function programmable LED outputs; (11)Reverse polarity detection and correction; (12)Read/write register bit indication; (13)Industrial temperature (3.3V only).

Diagrams

AC101LKQTG diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AC101LKQTG
AC101LKQTG
Other

Data Sheet
Negotiable
